KUTAI VOLTAGE REGULATOR Direct Replacement for Basler VR63-4 and VR63-4A Regulator # EA04A

EA04A is a self excited brushless type AVR, which is able to directly replaces Basler VR63-4 and VR63-4A. It can also replace Marathon SE100A.
All manufacturer names and numbers are used for reference purpose only and do not imply that any part is the product of these manufacturer.

Features

• Voltage regulation less than +/-1%
• For use in 50/60 Hz brushless generators
• Optional 120/240 Vac sensing voltage switch *1
• Under frequency and over excitation protection
• EMI suppression
• Built-in high breaking capacity fuse
• Use with KUTAI EP200 Paralleling Module for parallel operation
• Basler Model VR63-4A only fits 120 Vac Generators, and Basler Model VR63-4 only fits 240 Vac Generators respectively, and both original Basler models do not have fuse protection.

Specifications

• Sensing & Power Input: Voltage 120(90 to 132) / 240(171 to 264) Vac DIP switch selectable, Frequency 50/60 Hz selectable
• Output:
  • Voltage Max. 32 Vdc @ 120 Vac input, Max. 63 Vdc @ 240 Vac input
  • Current Continuous 4A, Intermittent 7A for 60 seconds
  • Resistance: Min. 15 ohms, Max. 100 ohms
• Voltage Regulation: Less than +/-1% (with 4% engine governing)
• Build Up Voltage: 5Vac residual volts at power input terminal
• External Voltage Adjustment: +/-15% with 1K ohm 1 watt potentiometer
• Static Power Dissipation: Max. 8 watts
• EMI Suppression: Internal electromagnetic interference filtering
• Voltage Thermal Drift: Less than 5% at temperature range -40 to +70 °C
• Under Frequency Protection:(Factory Presets)50 Hz system presets knee point at 45 Hz, 60 Hz system presets knee point at 55 Hz
• Over Excitation Shutdown: Field volts shut down after a time delay if exciter field volts exceed 100+/-5 Vdc
• AVR Control Functions
• VOLT: Voltage adjustment
• STAB: Stability adjustment

Environment

• Operating Temperature: -40 to +60 °C
• Storage Temperature: -40 to +85 °C
• Relative Humidity: Max. 90%
• Vibration: 1.5 Gs @ 5 to 30 Hz, 5.0 Gs @ 30 to 500 Hz

Physical Specifications

• Dimensions:100.0 (L) x 68.5 (W) x 33.0 (H) mm
• Weight: 230 g +/-2%
